TECHNICAL DATA OF THE 1967 CADILLAC ELDORADO The 1967 Sales Brochure shows the following technical data:
ENGINE:
429 Cubic Inch (7,03l) V-8 (340 Horsepower - 254kw)
Maximum torque: 480 ft.-lbs. (650nm)
Bore and stroke: 4.13 x 4.0 Inches
Compression ratio: 10.5:1
Carburetor: Carter AFB Model 3903S
Exhaust System: Dual Exhaust to Muffler, One Outlet Pipe/Resonator from Muffler
TRANSMISSION:
Turbo Hydra-Matic, 3-Speed plus Torque Converter
WHEELBASE: 120 Inches - 3.05m
Length: 221 Inches - 5.61m
Width: 80.0 Inches - 2.03m
Height: 53.3 Inches - 1.35m
Weight: 4,950 Pounds - 2245kg
SUSPENSION:
Front: Independent, unequal-length wishbones, longitudinal torsion bars, anti-sway bar
Rear: Rigid axle, single-leaf springs, traction dampers, air leveling
STEERING:
2.75 Turns lock to lock
Type: Recirculating ball
Turning diameter: 41 Feet
429 Cubic Inch (7,03l) V-8 (340 Horsepower - 254kw)
Maximum torque: 480 ft.-lbs. (650nm)
Bore and stroke: 4.13 x 4.0 Inches
Compression ratio: 10.5:1
Carburetor: Carter AFB Model 3903S
Exhaust System: Dual Exhaust to Muffler, One Outlet Pipe/Resonator from Muffler
TRANSMISSION:
Turbo Hydra-Matic, 3-Speed plus Torque Converter
WHEELBASE: 120 Inches - 3.05m
Length: 221 Inches - 5.61m
Width: 80.0 Inches - 2.03m
Height: 53.3 Inches - 1.35m
Weight: 4,950 Pounds - 2245kg
SUSPENSION:
Front: Independent, unequal-length wishbones, longitudinal torsion bars, anti-sway bar
Rear: Rigid axle, single-leaf springs, traction dampers, air leveling
STEERING:
2.75 Turns lock to lock
Type: Recirculating ball
Turning diameter: 41 Feet
BRAKES:
Front: 12.0 x 2.75 Inch Cast Iron Drums
Rear: 12.0 x 2.0 Inch Cast Iron Drums
Total Swept Area: 179.5 Sq. Inches
Disc brakes were also available as an option for the front
CAPACITIES:
Alternator: 852 watts
Battery: 12 volt, 71 amp./hr.
Coolant: 18.6 quarts
Fuel: 24.0 gallons, Premium - 90.8l
Oil: 4.0 quarts
Weight distribution: F/R 58.0/42.0%
TIRES:
15 inch wheels, 5 bolt pattern
Size: 9.00 x 15 (U.S. Royal Laredo) = 235/75R15 radial equivalent
Inflation pressure: F/R 24 psi/22 psi
Front: 12.0 x 2.75 Inch Cast Iron Drums
Rear: 12.0 x 2.0 Inch Cast Iron Drums
Total Swept Area: 179.5 Sq. Inches
Disc brakes were also available as an option for the front
CAPACITIES:
Alternator: 852 watts
Battery: 12 volt, 71 amp./hr.
Coolant: 18.6 quarts
Fuel: 24.0 gallons, Premium - 90.8l
Oil: 4.0 quarts
Weight distribution: F/R 58.0/42.0%
TIRES:
15 inch wheels, 5 bolt pattern
Size: 9.00 x 15 (U.S. Royal Laredo) = 235/75R15 radial equivalent
Inflation pressure: F/R 24 psi/22 psi
